1. High cell efficiency (16%)
2.30 QC procedures
3.Unique frame design, easy installation
4.25 year life
5. 24 hour service
Features
1. High cell efficiency(up to 16%) with quality silicon materials for long term output stability and reliability.
2. High transmittance low iron tempered glass with enhanced stiffness and impact resistance
3. Unique frame design with high mechanical strength for easy Installation.Entire module certified to withstand high wind loads (240 Pascal) and snow loads (540 Pascal)
4 Advanced encapsulation material with multiplayer sheet lamination to provide efficient protection from the severest environmental conditions, PET sheet imported from Toyo Japan with advanced encapsulating material
5. Outstanding electrical performance under high temperature and low irradiance conditons,tolerance from +/- 3% ensures power output reliability
6. Excellent performance in harsh weather , Outstanding electrical performance under high temperature and low irradiance
7. Strictly quality control ensure the stability and reliability, totally 30 QC procedures
Solar panel applications
1.solar panel for Commercial and industrial building roof-top systems
2.solar modules for residential roof-top systems
3.solar panels for any commercial or industrial ground mount systems
4. Remote telecommunication power wupply
5. solar panel can use for Water pumping systems
6. solar panel can use for On-grid/Off-grid system
7. solar panel can use for Rural electrification and Solar farms
Solar panel quality and warranty
1.Peak power of single module in guaranteed in +-3%power tolerance.
2. Average power of modules in single order is guaranteed not less than the peak power
3. Rigorous quality control meets the highest international standard
5.No less than 97% output power in the first year
6.No more than 0.7% annual declination since the second year
7.25-year warranty at 80.2% power output
8.Product warranty enforced by CHUBB Insurance
9.Enhanced design for easy installation and long-term reliability
Technical Specification:
| Characteristics | ZDNY-260C60 | ||
| Max.Power(Pmax) | 260Wp | ||
| Optimum Operating Voltage(Vm) | 31.2V | ||
| Optimum Operating Current(Im) | 8.34A | ||
| Open-circuit Voltage(Voc) | 38.82V | ||
| Short-circuit Current(Isc) | 8.71A | ||
| Cell Efficiency | 18.1% | ||
| Solar Cell | Poly-crystalline 156*156mm | ||
| Output Tolerance(Pmax) | 0~+3% | ||
| Number of cells | 60 cells in series | ||
| Module Dimension | 1650*992*40mm | ||
| Weight | 19.5kg | ||
| Max.System Voltage | 1000V(TUV)/600V(UL) | ||
| Max.Series Fuse Rating | 15A | ||
| Output Cable | PV 4mm2 | ||
| Cable Length | 90cm±5 | ||
| Number of bypass diodes | 3 | ||
| Temperature cycling range | (-40~85°C) | ||
| NOTC | 47°C | ||
| Temperature coefficients of Isc | +(0.053±0.01)%/K | ||
| Temperature coefficients of Voc | -(0.35±0.001)%/K | ||
| Temperature coefficients of Pmax | -(0.40±0.05)%/K | ||
| Load Capacity | 285pcs/20'GP | ||
| 756pcs/40'HQ |
PAYMENT TERMS |
T/T, L/C |
SHIPPING |
Material in stock can be produce (procedure 5-20days) right away after pre-payment confirmation. COSCO Mearsk MSC ship to worldwide for safe shipping, don't worry about package damager or loss. It take 15-40 days to worldwide, Please note us your contact details include your phone number for easy contacting from shipping company officer.And we have about 12 years in solar panel production and exporting all over th world |
ABOUT US |
We are manufacturers and wholesalers of solar panels and renewable energy products. Our solar business has been established since 2006. Our engineers are experienced in solar and related accessories, if you buy from us you deal with not just a seller; the whole technical team is behind you and your business. OEM and ODM services are both available. We would like to be your best supplier in China. |
